Model | FR004340HP |
Vehicle models | FR004340HP |
Types of vehicles | Special Purpose Vehicle |
Driving Type | 6×4 |
Wheelbase mm | 4325+1350 |
Total Weight kg | 25000 |
Tare Weight | 13250 |
Rated Payload kg | 11620 |
Outside Dimensions(L×W×H) mm | 9950×2500×3400 |
Body shapes, sizes (L×W×H) mm | 6600×2360×1640 |
Body volume（m³） | 20 |
Engine brand | CUMMINES |
Engine power （KW） | 280/380HP |
Shaft NO. | 3 |
Approach / departure angle | 18/11.5 |
NO. tire | 10+1 |
Max speed(km/h) | 80 |
Leaf Spring NO. (F/R) | 9/12 |
Tire type | 12.00R20 |
Front/Rear Track Width | 2006/1850 |
Vertical vacuuming （m） | 4 |
Sprinkler the width (m) | Adjust as Require |
Range(m) | ≥20 |
